Alloy | Si | Fe | Cu | Mn | Mg | Zn | TI | Al | Others |
2024 | 0.5 | 0.5 | 3.8-4.9 | 0.3-0.9 | 1.2-1.8 | 0.25 | 0.15 | Reminder | 0.15 |
2014 | 0.5-1.2 | ≤0.7 | 3.9-5.0 | 0.4-1.2 | 0.2-0.8 | 0.25 | 0.15 | Reminder | 0.15 |
Alloy | Temper | Dimensions mm | Rm Mpa | Rpo2 Mpa | A % min. | A50mm % min. | HBW Typical value | |||
Da | Sb | min. | max. | min. | max. | |||||
2014 | O H111 | ≤200 | ≤200 | – | 250 | – | 135 | 12 | 10 | 45 |
T4 T4510 T4511 | ≤25 25<D≤75 75<D≤150 150<D≤200 | ≤25 25<S≤75 75<S≤150 150<S≤200 | 370 410 390 350 | – – – – | 230 270 250 230 | – – – – | 13 12 10 8 | 11 – – – | 110 110 110 110 | |
T6 T6510 T6511 | ≤25 25<D≤75 75<D≤150 150<D≤200 200<D≤250 | ≤25 25<S≤75 75<S≤150 150<S≤200 200<S≤250 | 415 460 465 430 420 | – – – – – | 370 415 420 350 320 | – – – – – | 6 7 7 6 5 | 5 – – – – | 140 140 140 140 140 | |
2024 | O H111 | ≤200 | ≤200 | – | 250 | – | 150 | 12 | 10 | 47 |
T3 T3510 T3511 | ≤50 50<D≤100 100<D≤200 200<D≤250 | ≤50 50<S≤100 100<S≤200 200<S≤250 | 450 440 420 400 | – – – – | 310 300 280 270 | – – – – | 8 8 8 8 | 6 – – – | 120 120 120 120 | |
T8 T8510 T8511 | ≤150
| ≤150
| 455 | – | 380 | – | 5 | 4 | 130 | |
Aerospace Industry: The high strength and good machine ability of 2 series aluminum bars make them ideal for aerospace applications. They are used in the manufacture of structural components, fittings, and other parts that require high strength and precision.
Automotive Industry: In the automotive sector, 2 series aluminum bars are used for high-performance parts such as pistons, cylinder heads, and other engine components where strength and durability are critical.
Industrial Machinery: Components that require high strength and resistance to wear and tear, such as gears, shafts, and hydraulic parts, are often made from 2 series aluminum bars.
Tooling and Dies: The excellent machineability of 2 series aluminum makes it suitable for use in the production of molds, dies, and other tooling components that require precise machining and high strength.
Consumer Electronics: In the electronics industry, 2 series aluminum bars are used for manufacturing durable and high-strength casings and components for various electronic devices.
Construction: Although less common due to its cost, 2 series aluminum can be used in construction for high-strength applications such as bridges, towers, and other structures where weight savings and durability are important.
Marine Applications: The corrosion resistance of 2 series aluminum, combined with its high strength, makes it suitable for use in marine environments, including boat hulls, masts, and other components exposed to harsh conditions.
Overall, the 2 series aluminum bar’s combination of high strength, excellent machineability, and good corrosion resistance makes it a versatile material for a wide range of high-performance applications.
Request a personalized quote for premium aluminum products tailored to your project needs at Henan Victor.
