Alloy | Si | Fe | Cu | Mn | Mg | Zn | TI | Al | Others |
2024 | 0.5 | 0.5 | 3.8-4.9 | 0.3-0.9 | 1.2-1.8 | 0.25 | 0.15 | Reminder | 0.15 |
2014 | 0.5-1.2 | ≤0.7 | 3.9-5.0 | 0.4-1.2 | 0.2-0.8 | 0.25 | 0.15 | Reminder | 0.15 |
Alloy | Temper | Wall thickness t
mm | Rm Mpa | Rpo2 Mpa | A % min. | A50mm % min. | HBW Typical value | ||
min. | max. | min. | max. | ||||||
2014 | O,H111 | All | – | 250 | – | 135 | 12 | 10 | 45 |
T4 T4510 T4511 | ≤25 25<T≤75 | 370 410 | – – | 230 270 | – – | 11 10 | 10 – | 110 110 | |
Open profile T5 | ≤25 25<T≤75 | 415 460 | – – | 370 415 | – – | 7 7 | 5 – | 140 140 | |
2014 | O,H111 | All | – | 250 | – | 150 | 12 | 10 | 47 |
T3 T3510 T3511 | ≤15 15<T≤50 | 395 420 | – – | 290 290 | – – | 8 8 | 6 – | 120 120 | |
T8 T8510 T8511 | ≤50
| 455 | – | 380 | – | 5 | 4 | 130 | |
