Alloy | Si | Fe | Cu | Mn | Mg | Zn | TI | Al | Others |
2024 | 0.5 | 0.5 | 3.8-4.9 | 0.3-0.9 | 1.2-1.8 | 0.25 | 0.15 | Reminder | 0.15 |
2014 | 0.5-1.2 | ≤0.7 | 3.9-5.0 | 0.4-1.2 | 0.2-0.8 | 0.25 | 0.15 | Reminder | 0.15 |
Alloy | Temper | Wall thickness t
mm | Rm Mpa | Rpo2 Mpa | A % min. | A50mm % min. | HBW Typical value | ||
min. | max. | min. | max. | ||||||
2014 | O,H111 | ≤20 | – | 250 | – | 135 | 12 | 10 | 45 |
T4 T4510 T4511 | ≤20 | 370 | – | 230 | – | 11 | 10 | 110 | |
T6 T6510 T6511 | ≤10 10<t≤40 | 415 450 | – – | 370 400 | – – | 7 6 | 5 4 | 140 140 | |
2024 | O,H111 | ≤30 | – | 250 | – | 150 | 12 | 10 | 47 |
T3 T3510 T3511 | ≤30 | 420 | – | 290 | – | 8 | 6 | 120 | |
T8 T8510 T8511 | ≤30 | 455 | – | 380 | – | 5 | 4 | 130 | |
Request a personalized quote for premium aluminum products tailored to your project needs at Henan Victor.
