Alloy | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Al | Others |
5A06 | 0.4 | 0.4 | 0.1 | 0.5-0.8 | 5.8-6.8 | \ | ≤0.2 | 0.02-0.1 | Reminder | 0.1 |
5052 | 0.25 | 0.4 | 0.1 | 0.1 | 2.2-2.8 | 0.15-0.35 | 0.1 | \ | Reminder | 0.15 |
5083 | 0.4 | 0.4 | 0.1 | 0.1-0.4 | 4.0-4.9 | 0.05-0.25 | 0.25 | 0.15 | Reminder | 0.15 |
5251 | 0.4 | 0.5 | 0.15 | 0.1-0.5 | 1.7-2.4 | 0.15 | 0.15 | 0.15 | Reminder | 0.15 |
5754 | 0.4 | 0.4 | 0.1 | 0.5 | 2.6-3.6 | 0.3 | 0.2 | 0.15 | Reminder | 0.15 |
Product | Temper | Specified thickness
mm | Tensile strength
Rm
MPa | Yeild strength
Rp0.2
MPa | Elongation min.
%
| Bend radius | Hardness HBWa | |||||
over | up to | min. | max. | min. | max. | A50min | A | 180° | 90° |
| ||
5A06 | H112 | 5 | 300 | 170 | 190 | 70 | 80 | 7 |
|
|
| 55 |
5052 | H111 | 0.2 | 0.5 | 170 | 215 | 65 |
| 12 |
| 0t | 0t | 47 |
0.5 | 1.5 | 170 | 215 | 65 |
| 14 |
| 0t | 0t | 47 | ||
1.5 | 3.0 | 170 | 215 | 65 |
| 16 |
| 0.5t | 0.5t | 47 | ||
3.0 | 6.0 | 170 | 215 | 65 |
| 18 |
|
| 1.0t | 47 | ||
6.0 | 12.5 | 165 | 215 | 65 |
| 19 |
|
| 2.0t | 46 | ||
12.5 | 80.0 | 165 | 215 | 65 |
|
| 18 |
|
| 46 | ||
H18 | 0.2 | 0.5 | 270 |
| 240 |
| 1 |
|
|
| 83 | |
0.5 | 1.5 | 270 |
| 240 |
| 2 |
|
|
| 83 | ||
1.5 | 3.0 | 270 |
| 240 |
| 2 |
|
|
| 83 | ||
H22 H32
| 0.2 | 0.5 | 210 | 260 | 130 |
| 5 |
| 1.5t | 0.5t | 61 | |
0.5 | 1.5 | 210 | 260 | 130 |
| 6 |
| 1.5t | 1.0t | 61 | ||
1.5 | 3.0 | 210 | 260 | 130 |
| 7 |
| 1.5t | 1.5t | 61 | ||
3.0 | 6.0 | 210 | 260 | 130 |
| 10 |
|
| 1.5t | 61 | ||
6.0 | 12.5 | 210 | 260 | 130 |
| 12 |
|
| 2.5t | 61 | ||
12.5 | 40.0 | 210 | 260 | 130 |
|
| 12 |
|
| 61 | ||
5083 | H321b | ≥1.5 | 3.0 | 305 |
| 215 |
| 8 |
| 3.0t | 2.0t | 89 |
3.0 | 6.0 | 305 |
| 215 |
| 10 |
|
| 2.5t | 89 | ||
6.0 | 12.5 | 305 |
| 215 |
| 12 |
|
| 4.0t | 89 | ||
12.5 | 40.0 | 305 |
| 215 |
|
| 10 |
|
| 89 | ||
40.0 | 80.0 | 285 |
| 200 |
|
| 10 |
|
| 83 | ||
H111 | 0.2 | 0.5 | 275 | 350 | 125 |
| 11 |
| 1.0t | 0.5t | 75 | |
0.5 | 1.5 | 275 | 350 | 125 |
| 12 |
| 1.0t | 1.0t | 75 | ||
1.5 | 3.0 | 275 | 350 | 125 |
| 13 |
| 1.5t | 1.0t | 75 | ||
3.0 | 6.3 | 275 | 350 | 125 |
| 15 |
|
| 1.5t | 75 | ||
6.3 | 12.5 | 270 | 345 | 115 |
| 16 |
|
| 2.5t | 75 | ||
12.5 | 50.0 | 270 | 345 | 115 |
|
| 15 |
|
| 75 | ||
H22 | 0.2 | 0.5 | 305 | 380 | 215 |
| 5 |
| 2.0t | 0.5t | 89 | |
0.5 | 1.5 | 305 | 380 | 215 |
| 6 |
| 2.0t | 1.5t | 89 | ||
1.5 | 3.0 | 305 | 380 | 215 |
| 7 |
| 3.0t | 2.0t | 89 | ||
3.0 | 6.0 | 305 | 380 | 215 |
| 8 |
|
| 2.5t | 89 | ||
6.0 | 12.5 | 305 | 380 | 215 |
| 10 |
|
| 3.5t | 89 | ||
12.5 | 40.0 | 305 | 380 | 215 |
|
| 9 |
|
| 89 | ||
5251 | H111 | 0.2 | 0.5 | 160 | 200 | 60 |
| 13 |
| 0t | 0t | 44 |
0.5 | 1.5 | 160 | 200 | 60 |
| 14 |
| 0t | 0t | 44 | ||
1.5 | 3.0 | 160 | 200 | 60 |
| 16 |
| 0.5t | 0.5t | 44 | ||
3.0 | 6.0 | 160 | 200 | 60 |
| 18 |
|
| 1.0t | 44 | ||
6.0 | 12.5 | 160 | 200 | 60 |
| 18 |
|
| 2.0t | 44 | ||
12.5 | 50.0 | 160 | 200 | 60 |
|
| 18 |
|
| 44 | ||
H18 | 0.2 | 0.5 | 255 |
| 230 |
| 1 |
|
|
| 79 | |
0.5 | 1.5 | 255 |
| 230 |
| 2 |
|
|
| 79 | ||
1.5 | 3.0 | 255 |
| 230 |
| 2 |
|
|
| 79 | ||
H32 | 0.2 | 0.5 | 190 | 230 | 120 |
| 4 |
| 1.5t | 0t | 56 | |
0.5 | 1.5 | 190 | 230 | 120 |
| 6 |
| 1.5t | 1.0t | 56 | ||
1.5 | 3.0 | 190 | 230 | 120 |
| 8 |
| 1.5t | 1.0t | 56 | ||
3.0 | 6.0 | 190 | 230 | 120 |
| 10 |
|
| 1.5t | 56 | ||
6.0 | 12.5 | 190 | 230 | 120 |
| 12 |
|
| 2.5t | 56 | ||
12.5 | 25.0 | 190 | 230 | 120 |
|
| 12 |
|
| 56 | ||
5754 | H111 | 0.2 | 0.5 | 190 | 240 | 80 |
| 12 |
| 0.5t | 0t | 52 |
0.5 | 1.5 | 190 | 240 | 80 |
| 14 |
| 0.5t | 0.5t | 52 | ||
1.5 | 3.0 | 190 | 240 | 80 |
| 16 |
| 1.0t | 1.0t | 52 | ||
3.0 | 6.0 | 190 | 240 | 80 |
| 18 |
| 1.0t | 1.0t | 52 | ||
6.0 | 12.5 | 190 | 240 | 80 |
| 18 |
|
| 2.0t | 52 | ||
12.5 | 100.0 | 190 | 240 | 80 |
|
| 17 |
|
| 52 | ||
H18 | 0.2 | 0.5 | 290 |
| 250 |
| 1 |
|
|
| 88 | |
0.5 | 1.5 | 290 |
| 250 |
| 2 |
|
|
| 88 | ||
1.5 | 3.0 | 290 |
| 250 |
| 2 |
|
|
| 88 |
5 series aluminum (e.g., 5052, 5083) is widely used in aircraft components and shipbuilding due to its high strength-to-weight ratio, corrosion resistance, and durability in harsh environments. It is ideal for structural parts like hulls, decks, and fuel tanks.
These alloys are employed in high-performance vehicles for components such as battery cooling systems, liquid-cooled heat exchangers, and structural parts. Their thermal conductivity and resistance to stress make them suitable for electric vehicle battery packs and energy storage systems.
5 series aluminum plates are used in building exteriors, billboards, and office lattice decorations due to their aesthetic appeal and corrosion resistance. They are also applied in anti-slip flooring for buses, elevators, and industrial facilities, leveraging their durability and safety features.
The series is utilized in aluminum extrusions for machinery, often paired with specialized hardware like insertion nuts (e.g., MISUMI’s spring nuts and stopper-integrated nuts) for modular assembly. These components are critical in constructing lightweight yet robust industrial frameworks.
Alloys like 5052 are popular in cookware production (e.g., pots, pans) due to their formability, corrosion resistance, and compatibility with deep-drawing processes. They are also used in kitchen utensils and food storage solutions.
High-magnesium 5 series plates are tailored for electronic backboards, including screen backboards, where lightweight and structural integrity are prioritized. They are also used in heat exchange components for electronics cooling.
While not explicitly mentioned for 5 series, aluminum tread plates (a category that includes 5xxx alloys) are used in cold storage facilities for flooring and wall panels due to their corrosion resistance and thermal properties, similar to 1xxx series applications.
Key Properties Driving These Uses
Corrosion Resistance: Ideal for marine and outdoor applications.
High Strength and Formability: Suitable for structural and deep-drawn components.
Lightweight: Critical for aerospace and automotive industries.
Thermal Conductivity: Essential for battery and electronics cooling systems.
With its comprehensive performance, 5-series aluminum plates occupy an important position in lightweight, corrosion resistance and high strength demand scenarios, and there is still potential for expansion in the future in the fields of new energy and environmental protection equipment.
Request a personalized quote for premium aluminum products tailored to your project needs at Henan Victor.
