Alloy | Si | Fe | Cu | Mn | Mg | Cr | Zn | TI | Al | Others |
6060 | 0.3-0.6 | 0.1-0.3 | 0.1 | 0.1 | 0.35-0.6 | 0.05 | 0.15 | 0.1 | Reminder | 0.15 |
6061 | 0.4-0.8 | 0.7 | 0.15-0.4 | 0.15 | 0.8-1.2 | 0.04-0.35 | 0.25 | 0.15 | Reminder | 0.15 |
6082 | 0.7-1.3 | 0.5 | 0.1 | 0.4-1.0 | 0.6-1.2 | 0.25 | 0.2 | 0.1 | Reminder | 0.15 |
Alloy | Temper | Wall thickness t
mm | Rm Mpa | Rpo2 Mpa | A % min. | A50mm % min. | HBW Typical value | ||
min. | max. | min. | max. | ||||||
6060 | T4 c | ≤15 | 120 | – | 60 | – | 16 | 14 | 50 |
T5 | ≤15 | 160 | – | 120 | – | 8 | 6 | 60 | |
T6 c | ≤15 | 190 | – | 150 | – | 8 | 6 | 70 | |
T64 cd | ≤15 | 180 | – | 120 | – | 12 | 10 | 60 | |
T66 c | ≤15 | 215 | – | 160 | – | 8 | 6 | 75 | |
6061 | O,H111 | ≤25 | – | 150 | – | 110 | 16 | 14 | 30 |
T4 c | ≤25 | 180 | – | 110 | – | 15 | 13 | 65 | |
T6 c | ≤5 ≤5≤t≤25 | 260 260 | – – | 240 240 | – – | 8 10 | 6 8 | 95 95 | |
6082 | O,H111 | ≤25 | – | 160 | – | 110 | 14 | 12 | 35 |
T4 c | ≤25 | 205 | – | 110 | – | 14 | 12 | 70 | |
T6 c | ≤5 5≤t≤25 | 290 310 | – – | 250 260 | – – | 8 10 | 6 8 | 95 95 |
Request a personalized quote for premium aluminum products tailored to your project needs at Henan Victor.
