Alloy | Si | Fe | Cu | Mn | Mg | Cr | Zn | TI | Al | Others |
7075 | 0.4 | 0.5 | 1.2-2.0 | 0.3 | 2.1-2.9 | 0.18-0.28 | 5.1-6.1 | 0.2 | Reminder | 0.15 |
Alloy | Temper | Dimensions mm | Rm Mpa | Rpo2 Mpa | A % min. | A50mm % min. | HBW Typical value | |||
Da | Sb | min. | max. | min. | max. | |||||
7075 | O, H111 | ≤200 | ≤200 |
| 275 |
| 165 | 10 | 8 | 60 |
T6, T6510, T6511 | ≤25 | ≤25 | 540 |
| 480 |
| 7 | 5 | 150 | |
25<D≤100 | 25<D≤100 | 560 |
| 500 |
| 7 |
| 150 | ||
100<D≤150 | 100<D≤150 | 530 |
| 470 |
| 6 | 5 | 150 | ||
150<D≤200 | 150<D≤200 | 470 |
| 400 |
| 5 |
| 150 | ||
T73, T73510, T73511c | ≤25 | ≤25 | 485 |
| 420 |
| 7 | 5 | 135 | |
25<D≤75 | 25<D≤75 | 475 |
| 405 |
| 7 |
| 135 | ||
75<D≤100 | 75<D≤100 | 470 |
| 390 |
| 6 |
| 135 | ||
100<D≤150 | 100<D≤150 | 440 |
| 360 |
| 6 |
| 135 | ||
Aerospace: Aircraft fittings, wings, fuselage components, and other structural parts.
Automotive: High-stress parts such as drive shafts, suspension components, and gears.
Sporting Goods: Bicycle frames, rock climbing equipment, and other high-performance gear.
Industrial Machinery: Gears, shafts, and other components requiring high strength and durability.
Marine: Boat fittings and other marine hardware, often with additional corrosion protection.
Its high strength-to-weight ratio and fatigue resistance make it ideal for applications where both strength and lightweight properties are critical.
Request a personalized quote for premium aluminum products tailored to your project needs at Henan Victor.
